Showing 145–156 of 182 results
-
A-Frames and Racks by Abaco Machines
ABACO Slab Rack SRK10 & SRK10R
These racks are ideal for Granite Shops with limited storage space as it can handle many pieces of different sizes and materials.
- The rack consists of two steel bases of 10 feet (3048mm) and 20 poles 2 inches x 2 inches x 59 inches (50 x 50 x 1500mm) with rubber caps to protect the stored material.
- The Slab Rack is also available with rubber-lined poles for added protection of your slabs.
-
A Frames and Racks by Groves Incorporated
GROVES Bundle Rack (With 60” Posts)
- Heavy-duty powder-coated finish.
- Post height options available (40″, 60″ or 80″)
- Complete with an 11” connector tube for butting rails together in a straight line for the desired length
- Rails built with 2” square holes spaced 4” apart (10 holes). A steal plate with identical holes is welded and boxed inside the rail, 1” up from the bottom
- 2” square tube posts and 2” square rubber post caps to separate bundles and slabs
- Rails designed with slots to hold 2 x 4’s which protect the slab edges and the finish on the rails (2 x 4’s not included)
- Maximum weight allowed per opening is 9,000 lbs. (4,500 lb. per post)
-
A Frames and Racks by Groves Incorporated
GROVES Heavy-Duty Bundle Rack – Long 90″
- Heavy-duty powder-coated finish
- Rails built with 2.5″ square holes spaced 5″ apart. A steal plate with identical holes is welded and boxed inside the rail, 1″ up from the bottom.
- 2.5″ square tube posts and 2.5″ square rubber post caps to separate bundles and slabs
- It must have a 12” overhang on each side
- 90″ Rails are designed with slots to hold 2 x 4’s, which protect the slab edges and the finish on the rails (2 x 4s not included)
- Complete with an 11″ connector tube for butting rails together in a straight line for the desired length
- Use .5″ holes located on the bottom flange for securing rails to the floor
-
A Frames and Racks by Groves Incorporated
GROVES Backsplash Package 1
- Space-saving storage system for backsplashes, slabs, or combined storage applications
- Heavy-duty modular rails can be connected end-to-end for customized storage lengths
- Provides 8 dedicated backsplash storage sections per 5-foot rail section
- Supports up to 9,000 lbs of slab storage between two posts
- Each backsplash section supports up to 500 lbs when evenly distributed
- Reinforced 2″ square post openings deliver exceptional strength and stability
- Powder-coated construction designed for demanding fabrication environments
-
A Frames and Racks by Groves Incorporated
GROVES Heavy-Duty Bundle Rail Backsplash Package
- Heavy duty powder coated outside rails are designed with slots to hold 2 x 4
- Package includes: Qty 2 = BR-5, Qty 4 = SP-60, Qty 16 = BSB-23, Qty 2 = 11″ connector tubes
- Rails shipped with an 11″ connector tube for butting rails together in a straight line.
- Two rows with four levels each provide eight levels of backsplash storage.
- Outside rails have 2″ square holes spaced 4″ apart on the top. A steel plate with identical holes is welded and boxed inside the rails, 1″ up from the bottom.
- Note: When assembled, the overall usable height of the post is 5.5″ less than listed. Example: A 60″ post will be 54.5″ above the top of the outside rail.
- Maximum weight capacity per bundle: 6,000 LBS. (3,000 LBS. PER POST)
-
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Carts and Dollies Accessories, Shop & Installation
GROVES Transport Rack Caster Kits for TR-4482 and TR-4496
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Carts and Dollies Accessories, Shop & InstallationGROVES Transport Rack Caster Kits for TR-4482 and TR-4496
- 8″ diameter roller bearing wheels
- Two swivel casters with brakes on one end and two rigid on the other
- Quick release mounting pins and caster stems change rack from mobile to stationary in seconds
- Weight 40 lbs
-
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Carts and Dollies, Carts and Dollies Accessories, Shop & Installation
GROVES Adjustable Foot Locks
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Carts and Dollies, Carts and Dollies Accessories, Shop & InstallationGROVES Adjustable Foot Locks
- Heavy-duty adjustable foot locks for carts, dollies, and material handling systems
- Provides secure locking and enhanced stability during transport and storage
- Integrated brake lock mechanism prevents unwanted movement
- Foot-operated design allows quick and easy engagement and release
- Supports safe loading, unloading, and equipment positioning
- Durable construction built for industrial and warehouse environments
- Fast installation and versatile compatibility with various equipment types
- Ensures reliable holding power and improved workplace safety
-
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Shop & Installation
GROVES MWCK-5 Windshield Rack Caster Kit
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Shop & InstallationGROVES MWCK-5 Windshield Rack Caster Kit
- Designed to convert stationary windshield and auto glass racks into mobile storage systems
- Heavy-duty caster kit improves material handling efficiency and workflow
- Durable powder-coated finish resists rust and corrosion
- Provides smooth and reliable movement for glass racks and transport systems
- Reduces effort when moving heavy racks and fragile materials
- Easy-installation design allows quick upgrades to existing storage racks
- Ideal for auto glass shops, garages, and industrial facilities
- Enhances safety, mobility, and flexibility in busy work environments
-
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Carts and Dollies, Carts and Dollies Accessories, Shop & Installation
GROVES Pneumatic and Semi-Pneumatic
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Carts and Dollies, Carts and Dollies Accessories, Shop & InstallationGROVES Pneumatic and Semi-Pneumatic
- Heavy-duty pneumatic and semi-pneumatic tires for carts, racks, dollies, and industrial equipment
- Pneumatic tire design provides superior shock absorption and smooth movement on uneven surfaces
- Semi-pneumatic tires offer maintenance-free, non-flat performance with reliable cushioning
- Available in 8″ and 10″ diameters to suit a wide range of applications
- Reduces vibration, noise, and equipment wear during transport
- Durable construction supports heavy loads and demanding industrial use
- Enhanced tread design delivers dependable traction and stability
- Ideal for warehouses, fabrication shops, workshops, and material handling environments
-
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Carts and Dollies, Carts and Dollies Accessories, Shop & Installation
GROVES Rigid Caster
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Carts and Dollies, Carts and Dollies Accessories, Shop & InstallationGROVES Rigid Caster
- Heavy-duty rigid caster designed for glass handling equipment, racks, and industrial carts
- Available in 5″ and 8″ diameters to fit a variety of applications
- Supports loads of up to 1,000 lbs per caster
- Rigid design provides stable, straight-line movement and controlled transport
- Built for demanding commercial, warehouse, and industrial environments
- Rugged construction ensures long-lasting durability and reliable performance
- Ideal for storage racks, transport carts, and heavy material handling systems
- Helps move large and heavy loads safely and efficiently
-
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Carts and Dollies, Carts and Dollies Accessories, Shop & Installation
GROVES Roller Bearing Caster
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Carts and Dollies, Carts and Dollies Accessories, Shop & InstallationGROVES Roller Bearing Caster
- Heavy-duty roller bearing caster designed for smooth and reliable industrial movement
- 3″ diameter lightweight design (1.2 lbs) with strong load-bearing capability
- Roller bearing system reduces friction for effortless swiveling and transport
- 360-degree swivel function enhances maneuverability in tight spaces
- Compatible with heavy-duty braking caster systems for secure stopping power
- Ideal for glass handling systems, warehouse carts, and material transport equipment
- Built for durability and frequent industrial use in demanding environments
- Easy installation for quick replacement and improved equipment performance
-
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Carts and Dollies, Carts and Dollies Accessories, Shop & Installation
GROVES Rubber Kit
Groves Parts & Accessories, A Frames and Racks Accessories, A-Frames and Racks, Carts and Dollies, Carts and Dollies Accessories, Shop & InstallationGROVES Rubber Kit
- Includes base and upright rubber pieces for versatile rack and cart compatibility
- Provides superior grip and stability for safer material handling
- Helps prevent slipping, shifting, and accidental movement during transport
- Protects glass and sensitive materials from scratches and impact damage
- Heavy-duty black rubber construction for long-lasting durability
- Extends the service life of racks, carts, and handling equipment
- Ideal for workshops, warehouses, fabrication shops, and construction sites
- Easy installation for quick replacement of worn or damaged rubber components
