Alpha Quad Blades
Alpha Quad Blades combine the exceptional performance of the Alpha® Plus diamond blade with a unique design for flush cutting applications. Compatible with the exclusive Quad Drive Adapter, these blades eliminate the need for a lock nut, allowing a threaded arbor connection for angle grinders in “flush cutting” mode. The Quad Drive Adapter also accommodates larger diameters, enabling use with the grinder’s safety guard in place. Perfect for fabricators making precise 90° inside corners, monument builders cleaning up large saw cut marks, and contractors converting their angle grinder into a versatile cutting tool on-site. Sculptors also appreciate Alpha Quad’s ability to reach tight corners and hard-to-access areas. Offering unmatched performance for specialized applications, Alpha Quad Blades deliver precision, safety, and versatility in one exceptional cutting solution.
Quad Blades Main Features
- Requires Quad Drive to fit High-Speed Angle Grinder
- Fits most popular High-speed Angle Grinders
- Specially Designed for Flush Cutting
- Best Dry Cutting Turbo Blade on the Market
- Chip-Free Cutting on Most Demanding Applications
Alpha Plus Blades Specifications
| Part No. | Size | Thickness | Maximum RPM | Arbor(s) | For Use On |
|---|---|---|---|---|---|
| DA04AH | 4″ | 2.1mm | 14,500 | 20mm Quad Drive | Angle Grinder |
| DA05SH | 5″ | 2.1mm | 12,200 | 20mm Quad Drive | Angle Grinder |
| DA06AH | 6″ | 2.1mm | 10,100 | 20mm Quad Drive | Angle Grinder |
| DA07AH | 7″ | 2.3mm | 8,400 | 20mm Quad Drive | Angle Grinder |
| DA08AH | 8″ | 2.3mm | 7,400 | 20mm Flange with 8 holes | Angle Grinder |
| DA09AH | 9″ | 2.5mm | 6,600 | 20mm Flange with 8 holes | Angle Grinder |
| DA11AH | 10″ | 2.5mm | 5,900 | 20mm Flange with 8 holes | Angle Grinder |
Alpha Plus Blades Related Documents
| Document Type | Link |
|---|---|
| Safety Data Sheet | Diamond Tools Cutting Blade |
| Reference | Quad_HelpfulHints |
| Reference | Quad_HowToUse |
| Flyer | Blade Selection Guide |
| Flyer | Hardscape Blade Chart |
| Flyer | Cutting System Overview |
Additional Information
| PartNo | UPC Code | Pkg. Weight (lbs) | Package Dimensions | Commodity Code | Country Of Origin |
|---|---|---|---|---|---|
| DA04AH | 749173460128 | 0.30 | 5.25in x 4.5in x 0.25in | 8202.91.0000 | Japan |
| DA05SH | 749173460159 | 0.40 | 6in x 5.5in x 0.25in | 8202.91.0000 | Japan |
| DA06AH | 749173460173 | 0.70 | 7in x 6.5in x 0.25in | 8202.91.0000 | Japan |
| DA07AH | 749173460203 | 0.90 | 7.5in x 7.5in x 0.25in | 8202.91.0000 | Japan |
| DA08AH | 749173460227 | 1.10 | 8.5in x 8.5in x 0.25in | 8202.91.0000 | Japan |
| DA09AH | 749173460241 | 1.90 | 10.5in x 9.5in x 0.25in | 8202.91.0000 | Japan |
| DA11AH | 749173460272 | 2.20 | 10.5in x 10.5in x 0.25in | 8202.91.0000 | Japan |
Frequently Asked Questions
What applications are the Alpha® Quad blades designed for?
The Alpha® Quad blades are designed for flush cutting and making 90 degree inside corners.
Can I use the Alpha® Quad blade for groove cutting application?
No. We recommend using the Alpha® Groove Cutter together with the Alpha® Universal Safety Guard Kit for groove cutting application.
Can I use the Alpha® Quad blade without the BAH or FAH adapters?
No. The Alpha® Quad blade must always be used together with the BAH or FAH adapters. Alpha® does not recommend mounting the Quad blade directly onto the flange of a power tool without the BAH or FAH adapter due to the countersunk holes drilled within the core of the blade.
On what granite classification do you recommend using the Alpha® Quad blades?
The Alpha® Quad blades are best suited for all granite classifications; however; this particular blade works best on hard granite classification material.
The Alpha® Quad is a dry cutting blade, can I use this blade for wet application?
Yes. Wet cutting will generally increase blade life as well as keep harmful dust (Silica) out of the air.
What is the cutting edge rim height of the Alpha® Quad blades?
Alpha® Quad blades cutting edge rim height is 8mm.
What is the spindle size required for use of the BAH-5/8 and FAH-5/8 adapters?
These adapters have a 5/8”-11 thread size.
Does Alpha® offer other spindle sizes for the BAH and FAH adapters?
Yes. Other spindle sizes are available. Please contact your dealer or Alpha® directly to learn more about these other thread sizes.
Can I use the Alpha® Quad blade on my polishing tool?
No. The RPM speeds of polishers are too slow. Diamond blades are recommended to be used on high-speed angle grinders rated for your blade diameter being used.
