Aardwolf Electric Vacuum Lifters AEVLP8-2000
Aardwolf Electric Vacuum Lifters AEVLP8-2000 are designed to lift flat, non-porous materials, such as metal sheets, using an electric vacuum pump. Available in configurations with 1, 4, or 8 pads, the main beam and vacuum pad positions are adjustable to handle different sheet sizes. Depending on the model, the system supports loads up to 2000 kg and sheet dimensions up to 236.2″ × 70.9″, making it ideal for workshops and industrial environments.
Each unit features a pressure-monitoring system, automatic vacuum pump reactivation in the event of a pressure loss, and audio-visual safety alerts. Battery-powered alarms (3.7V LiPo) provide up to 7 hours of continuous operation and 720 hours of standby. The electric motor operates on 3-phase 380V and delivers vacuum flow rates up to 8.7 m³/h, depending on the model, ensuring safe, reliable, and efficient lifting for various sheet-handling tasks.
You might also want to take a look at the diverse line of Aardwolf Stone Lifters, where you will probably find the best solution for your Granite Shop.
Electric Vacuum Lifters AEVLP8-2000 Main Features
Among the features of this wonderful Vacuum Lifter, we find:
- Adjustable Beam and Pad Positions: Suitable for handling different sheet sizes.
- Lifting Capacities: Available models support 500 kg, 1000 kg, or 2000 kg loads.
- Safety Alerts: Audio-visual indicators notify the operator when pressure drops.
- Automatic Pump Activation: The system automatically restarts the vacuum pump if pressure drops below the safe level.
- Battery-Powered Alarm: Runs on a 3.7V LiPo battery, up to 7 hours continuous use and 720 hours standby.
- Electric Motor: 3-phase 380V power input with vacuum flow rates up to 8.7 m³/h, depending on model.
AEVLP8-2000 Technical Specifications
| Property | Value |
|---|---|
| Number of pads | 8 |
| Pad diameter | 14″ |
| Working load limit | 4408 lb |
| Net weight | 816 lb |
| Packaging dimensions | 196 7/8″ x 47 1/4″ x 51 1/8″ |
Battery Information for the alarm system
| Property | Value |
|---|---|
| Power supply | 3.7V LiPo battery |
| Battery capacity | 2000 mAh x 1 |
| Adapter | DC 5V-1A |
| Standby time | 720 hours |
| Charging cycle | 1000 times |
| Charging time | 2 hours |
| Non-stop working time | 7 hours |
| 6-month warranty | – |
Motor Information
| Property | Value |
|---|---|
| Input supply | AC 380-3Phase 50/60Hz |
| Vacuum flow rate | 7.6/8.7 m3/hour |
